1967. Recentlly cleaned and serviced. One of the MP1's channel is an instrument input with volume, treble, bas, and reverb controls, while the other is a microphone input with volume and tone controls. The tremolo uses an LDR (like a Ampeg Gemini I) to limit the instrument signal post preamp. The reverb uses a 12AU7A as phase inverter for a 25KCT:8ohm reverb transformer (This was an interesting step for engineering, all the previous Estey reverb circuits used a tube stage as a driver). $399 CDN
Years | late 1965-1967 |
Series | Pro Series |
Channels | two |
Power | 2x 7189A |
Power Bias | fixed bias |
Preamp | 2x 7025 |
Reverb | 12AU7A |
Tremolo | NE-2H bulb, 12AU7, 1869-D bulb. |
Phase Inverter | 12AU7A |
Speaker | 1x 12" |
Rectifier | solid state |
Output Trans | 8K:8ohm |
Output | 30 watts peak |
Weight | 40 lbs. |
